Monocular Cooler

Introduction of Monocular Cooler

The application scope of cooler is very wide, and the most commonly used mode is the configuration of cooling machine and rotary kiln, which is used for cooling materials after calcining by the rotary kiln. The cooling machine produced by our company can make the heat generated in the calcining process return back to the rotary kiln, which saves the production cost. The second is to operate with the drying machine, which play a great role in compound fertilizer production.

Cooling machine produced by our company can cool the granular or powdered materials, and the cooling processes for all kinds of materials can be designed by our company.

Features:

1. The wide ranges of cooled materials, all kinds of materials can be customized the cooling equipment.
2. Fast cooling speed, higher product quality after the fast cooling.
3. Large capacity, large processing capacity at one time.
4. The equipment has good sealing performance, no pollution to the environment, which can also prevent energy loss.
5. The heat generated during can return back into the kiln to save the production cost.
6. The temperature of cooling machine can be adjusted to adapt to different cooling needs of materials.
7. Uniform cooling effect, stable operation.

The Common Problems and Analysis of Cooling Machine:

1. The cooling effect is not good; the actual production efficiency is not high.

a. The grate has uneven distribution of materials.
b. The cooling machine has bad sealing effect with air leakage.
c. The failure of cooling fan.

2. The feeding port plug of cooling machine.

a. The clinker is in bulk or the large kiln crust fall off in the rotary kiln.
b. The grate fault, but rotary kiln is still feeding.
c. The second-time air temperature is low.

3. The grate temperature is high.

a. The clinker size is too small
b. The cooling air is not suitable.
c. A lot of clinker accumulation, which cannot be timely cooled.
d. The grate is too fast.

4. The discharging temperature of cooling machine is too high.

1) The air of the cooling fan is insufficient
2) The grate is too fast.
3) Inadequate cooling caused by clinker blocks.
4) High temperature zone in the cooler to the cooling end.

If you are looking for grate cooler used in cement plant, Zhongde Heavy Industries is the professional cooler machine manufacturer, and we can provide high quality cooler for customer with favorable price. For more detailed information, please contact us!

Technical Parameter
