High Frequency Vibrating Screen

High Frequency Vibrating Screen

High frequency screen is short for high frequency vibrating screen. As the name suggests, high frequency vibrating screen is the equipment which uses high vibration frequency to screen materials.

Email us at info@sinoftm.com

Advantage

  • Low energy consumption
  • High screening frequency
  • Strong production capacity
High Frequency Vibrating Screen

Get more information about theHigh Frequency Vibrating Screen

Introduction of High Frequency Vibrating Screen

High frequency screen is short for high frequency vibrating screen. As the name suggests, high frequency vibrating screen is the equipment which uses high vibration frequency to screen materials. It has uniform grain size and high quality product, which can greatly improve the processing ability of supporting equipment (increase 5% -10%).

High frequency vibrating screen is widely applied to the dry and wet screening, grading, dehydration and fine classification for all kinds of materials in mineral processing, coal, chemical industry, brick making, food, pharmaceutical, alkali, chemical fertilizer, paper and other industries.

High Frequency Vibrating Screen

Features:

1. Simple structure, convenient maintenance, durable, low failure rate.

2. High frequency, small amplitude, high screening frequency.

3. The stack layer screen has long service life, which is wear-resistant and anti blocking.

4. The inclination of vibration screen surface can be adjusted.

5. The whole screen surface can be used as feeding surface, which has large screen area.

6. The vibration frequency and amplitude can be adjusted, which can be set according to the discharging granularity.

7. It is equipped with rubber isolator, the equipment has stable running, which produces less dust and low noise.

The Regular Inspection of the Screen:

1. Check the situations of vibration exciter, the screen surface and bolt supporting device, if the vibration screen is loose, it should be tightened.

2. Check the using effect of the transmission device and the locking condition of the connecting bolt; check the tensioning degree of belt, fasten it if it is necessary.

3. Check the vibrating screen, you must pay special attention to whether the flywheel weight block is fixed, if it is not fixed, the flywheel may be out of the vibrating screen without balance, which may lead to accidents.

4. Regularly inspect the wear of screen surface, timely repair or replace it to ensure the production efficiency.

Daily Maintenance of High Frequency Screen:

1. Always observe the feeding concentration to ensure the discharge quality of the screening equipment

2. The vibration exciter and control box need to be protected, which should be prevented from water and slurry, thus causing a short circuit and jam.

3. Check whether the bolts are loose, timely tightening or replace them.

4. Adjust the amplitude according to the production needs to ensure efficient operation of the equipment.

5. After using for a month, the screen surface should be turned for 180 degree to improve the utilization rate of screen surface.

Zhongde Heavy Industries is the professional high frequency screen manufacturer, which has complete models, reasonable prices and thoughtful services. If you want to know more information, please contact our online customer service or leave us a message. We will answer you as soon as possible!

Technical Parameter

Specification
 Model
Processing
capacity(t/h)
Power
(kw)
GPS-4 15-25 0.72
GPS-5 20-30 1.1
GPS-6 24-36 1.5
GPS-8 32-48 2.2



Specification
 Model
Processing
capacity
(t/h)
Power
(kw)
GPS-4 15-25 0.72
GPS-5 20-30 1.1
GPS-6 24-36 1.5
GPS-8 32-48 2.2
